SID4
Spectral Range VIS (400 - 750 nm) NIR (750 - 1100 nm)
Our entry-level yet high-resolution wavefront sensor covering the visible and NIR range, the SID4 is the perfect versatile tool for any laser or optical metrology application
Key Features
- High sensitivity - 2 nm RMS
- Achromaticity from 400-1100 nm without calibration
- Self-referenced – insensitive to vibrations & easy to align
Applications
• Laser testing, adaptive optics, and plasma diagnostics • Optics metrology and optical system alignment •
Specifications
| Wavelength range | 400-1100 nm |
| Aperture dimension | 4.73 x 3.55 mm² |
| Spatial resolution | 29.6 µm |
| Phase and Intensity sampling | 160 x 120 (> 19 000 points) |
| Resolution (Phase) | < 2 nm RMS |
| Accuracy (Absolute) | 10 nm RMS |
| Acquisition rate | 60 fps |
| Real-time processing frequency* | > 10 fps (full resolution) |
| Interface | Giga Ethernet |
| Dimensions (WxHxL) | 54 x 46 x 75.3 mm³ |
| Weight | ~250 g |
*with SID4 Software
